A manufacturer tests two ceramic tiles, G and U. A narrow ray of light is directed at each tile at an angle of incidence of 40° from the normal. A light sensor is placed at different angles from the normal on the side where reflected light is detected.
| Angle of sensor from the normal in ° | Sensor reading for tile G in lux | Sensor reading for tile U in lux |
|---|---|---|
| 20 | 14 | 74 |
| 30 | 26 | 82 |
| 40 | 480 | 85 |
| 50 | 25 | 79 |
| 60 | 13 | 70 |
Use the data and ideas about reflection to explain which tile would produce the clearer reflected image.
The angle of incidence is then changed to 55°. Predict the angle from the normal at which tile G will give its maximum sensor reading.
98 exam-style questions on AQA GCSE Physics 6.1 Waves in air, fluids and solids, covering 6.1.1 Transverse and longitudinal waves, 6.1.2 Properties of waves, 6.1.3 Reflection of waves, 6.1.4 Sound waves (HT only), and 6.1.5 Waves for detection and exploration (HT only). Each one has a worked solution and a mark scheme showing where the marks go.
