An ultrasound probe is used to inspect a thick ceramic component. The velocity of ultrasound in the ceramic is 5200 m/s.
The detector records two echoes.
| Source of echo | Time after the pulse is emitted |
|---|---|
| Hidden flaw | 28 μs28\ \mu\text{s}28 μs |
| Back surface of the component | 74 μs74\ \mu\text{s}74 μs |
Calculate the distance between the hidden flaw and the back surface of the component.
98 exam-style questions on AQA GCSE Physics 6.1 Waves in air, fluids and solids, covering 6.1.1 Transverse and longitudinal waves, 6.1.2 Properties of waves, 6.1.3 Reflection of waves, 6.1.4 Sound waves (HT only), and 6.1.5 Waves for detection and exploration (HT only). Each one has a worked solution and a mark scheme showing where the marks go.
