An earthquake produces a wave train that transfers energy horizontally through solid rock. Sensors record the movement of one point in the rock.
| Measurement | Result |
|---|---|
| Maximum horizontal displacement | 0.0 mm |
| Maximum vertical displacement | 2.4 mm |
| Position after the wave train has passed | Original position |
Use the measurements to explain what type of wave this is and whether the material in the rock is transferred overall.
A second earthquake wave is longitudinal and transfers energy through the rock in the same horizontal direction. Predict how a point in the rock moves as this wave passes.
98 exam-style questions on AQA GCSE Physics 6.1 Waves in air, fluids and solids, covering 6.1.1 Transverse and longitudinal waves, 6.1.2 Properties of waves, 6.1.3 Reflection of waves, 6.1.4 Sound waves (HT only), and 6.1.5 Waves for detection and exploration (HT only). Each one has a worked solution and a mark scheme showing where the marks go.
