A machine produces a short pulse at one end of a long block of soft, transparent plastic. The x-axis runs horizontally along the length of the block. A high-speed camera tracks the front of the pulse and a tiny marker P embedded in the block at x = 20.0 cm.
The horizontal position of marker P remains at x = 20.0 cm throughout the test.
| Time in ms | x-position of the front of the pulse in cm | Vertical displacement of marker P in mm |
|---|---|---|
| 0.0 | 0 | 0.0 |
| 2.0 | 10 | 0.0 |
| 4.0 | 20 | 0.0 |
| 6.0 | 30 | +2.0 |
| 8.0 | 40 | −2.0 |
| 10.0 | 50 | 0.0 |
Use the results to explain what is transferred along the block and what happens to the material of the block.
State the type of wave produced. Explain your answer.
98 exam-style questions on AQA GCSE Physics 6.1 Waves in air, fluids and solids, covering 6.1.1 Transverse and longitudinal waves, 6.1.2 Properties of waves, 6.1.3 Reflection of waves, 6.1.4 Sound waves (HT only), and 6.1.5 Waves for detection and exploration (HT only). Each one has a worked solution and a mark scheme showing where the marks go.
