Question 54
a.

State two practical applications of total internal reflection.

[2]
b.

Describe the two conditions that must be met for total internal reflection to occur.

[2]
c.

A light ray travels inside a triangular sapphire prism and is incident on the flat vertical boundary with the surrounding air at point PPP, as shown in the diagram.

Triangular sapphire prism showing a light ray incident at point P at an angle of 41 degrees to the normal

The angle of incidence at PPP is 41∘41^\circ41∘. The critical angle of the sapphire prism is 34.4∘34.4^\circ34.4∘. Describe the subsequent path of the light ray after it reaches point PPP.

[2]
d.

State the equation linking critical angle (ccc) and refractive index (nnn) for a medium in air.

[1]
e.

Calculate the refractive index of this sapphire prism. Give your answer to 3 significant figures.

[2]
