Question 19

An automated security gate unlocks ( $L = 1$ ) based on two inputs: a proximity sensor ( $P$ ) and a keycard reader ( $K$ ). The gate logic is represented by an XNOR (Exclusive NOR) gate:

\overline{P \oplus K}

Complete the truth table for the gate output $L$ .

P	K	L
0	0
0	1
1	0
1	1

[1]
