Question 3

A technician tests a three-core cable before connecting it to a mains-powered ventilation motor in a greenhouse. The table shows the potential of each wire relative to Earth.

Wire insulationPotential relative to Earth
brown228 V
blue2 V
green and yellow0 V
a.

Calculate the potential difference between the brown wire and the blue wire.

[1]
b.

An apprentice says, ‘The motor should be connected between the brown wire and the green-and-yellow wire because this gives a potential difference closer to 230 V.’

Evaluate the apprentice’s statement.

[3]
Markscheme
  1. GCSE
  2. /Physics
  3. /2.3 Domestic uses and safety

95 exam-style questions on AQA GCSE Physics 2.3 Domestic uses and safety, covering 2.3.1 Direct and alternating potential difference and 2.3.2 Mains electricity. Each one has a worked solution and a mark scheme showing where the marks go.
