A hydrocarbon vapour enters the bottom of a fractionating column and rises through five collecting trays.
The temperature control system is reset. The table shows the tray temperatures before and after the reset.
| Tray | Position | Temperature before reset / ∘C^\circ\mathrm{C}∘C | Temperature after reset / ∘C^\circ\mathrm{C}∘C |
|---|---|---|---|
| A | bottom | 320 | 350 |
| B | 240 | 270 | |
| C | 170 | 200 | |
| D | 120 | 150 | |
| E | top | 70 | 100 |
Hydrocarbon X has a boiling point of 184 ∘C184\,^\circ\mathrm{C}184∘C.
Explain how the tray on which hydrocarbon X is collected changes after the temperature control system is reset.
