9.1 Forces and vectors

EasyMediumHard
1234567891011121314151617181920212223242526272829303132333435
Question 13

One mooring line pulls a floating pontoon at an angle to a jetty. A force calculation record contains these three entries:

EntryForce recorded
1full mooring-line force
2component along the jetty
3component towards the jetty

All three entries are included when calculating the resultant force on the pontoon. Which change and reason corrects the record?

[1]
A

Delete the component along the jetty, because the other two entries together represent the full mooring-line force.

B

Reverse the full mooring-line force, because it must cancel the force represented by the two components.

C

Delete the full mooring-line force, because the two components together already have the same effect.

D

Delete both components, because each component separately has the same effect as the full mooring-line force.

Markscheme

9.1 Forces and vectors Questions

  1. GCSE
  2. /Physics
  3. /9.1 Forces and vectors

93 exam-style questions on Edexcel GCSE Physics 9.1 Forces and vectors, covering 9.1.1 Interactions and types of force, 9.1.2 Vector and scalar quantities, and 9.1.3 Vector diagrams and free body diagrams. Each one has a worked solution and a mark scheme showing where the marks go.
