A scientist prints a micrograph of a fungal cell. The printout includes a scale bar.
The table shows measurements from the printout.
| Feature | Length measured on printout in mm\text{mm}mm | Actual length in μm\mu\text{m}μm |
|---|---|---|
| Scale bar | 24 | 10 |
| Diameter of fungal cell | 72 | not known |
Calculate the magnification of the printed micrograph.
Calculate the actual diameter of the fungal cell in μm\mu\text{m}μm.
130 exam-style questions on OCR GCSE Biology 1.1 Cell structures, covering 1.1.1 Viewing cells with light microscopes, 1.1.2 Sub-cellular structures and functions, and 1.1.3 Electron microscopy and resolution. Each one has a worked solution and a mark scheme showing where the marks go.
