Question 2

A support cable pulls on a theatre light. An engineer resolves the cable force into horizontal and vertical components using a scale drawing.

The scale drawing uses a scale of 1.0 cm to represent 15 N.

Force arrowDirectionMeasured length
Original cable forceAlong the cable5.0 cm
Horizontal componentHorizontal4.0 cm
Vertical componentVertical3.0 cm
a.

Calculate the magnitude of each component of the cable force.

[2]
b.

A technician adds the magnitudes of the two components and concludes that their combined effect is 105 N.

Explain why the technician's conclusion is incorrect.

[2]
Markscheme
  1. GCSE
  2. /Physics
  3. /5.1 Forces and their interactions

107 exam-style questions on AQA GCSE Physics 5.1 Forces and their interactions, covering 5.1.1 Scalar and vector quantities, 5.1.2 Contact and non-contact forces, 5.1.3 Gravity, and 5.1.4 Resultant forces. Each one has a worked solution and a mark scheme showing where the marks go.
