A steel component is positioned between two electromagnets. The vertical forces acting on the component are balanced.
| Electromagnet | Horizontal force on the component |
|---|---|
| Left electromagnet | 18 N to the left |
| Right electromagnet | 32 N to the right |
Calculate the resultant horizontal force on the steel component.
The force exerted by the left electromagnet is increased by 6 N. A third electromagnet is used to put the steel component in equilibrium.
Calculate the magnitude and direction of the force that the third electromagnet must exert on the component.
107 exam-style questions on AQA GCSE Physics 5.1 Forces and their interactions, covering 5.1.1 Scalar and vector quantities, 5.1.2 Contact and non-contact forces, 5.1.3 Gravity, and 5.1.4 Resultant forces. Each one has a worked solution and a mark scheme showing where the marks go.
