Question 4
FThe Figure shows a circuit with two resistors connected in parallel to a 6.0 V battery.
Figure
a.[1]
State the potential difference across the 12 Ω resistor.
b.[2]
Use the equation: potential difference=current×resistance\text{potential difference} = \text{current} \times \text{resistance}potential difference=current×resistance
Calculate the reading on ammeter A2.
c.[1]
The reading on ammeter A3 is 1.0 A.
Calculate the reading on ammeter A1.
d.[2]
Calculate the total resistance of the circuit.
e.[2]
The total resistance of the circuit is less than the resistance of either resistor.
Explain why.
