Question 4
F

A student looks at human cheek cells stained with methylene blue.

The Figure shows the student's drawing of the cells.

Figure


a.

Give three ways the student could improve the drawing.

[3]
b.

Explain why the student first looks at the slide using the lowest power objective lens.

[2]
c.

The width of one cell in the drawing is 45 mm. The real width of the cell is 60 μm60\ \mu\text{m}60 μm.

The student writes:

magnification =45÷60=×0.75= 45 \div 60 = \times 0.75=45÷60=×0.75

Explain the mistake the student has made and calculate the correct magnification.

[3]
Markscheme

1.1 Cell structures Questions

  1. GCSE
  2. /Biology
  3. /1.1 Cell structures

130 exam-style questions on OCR GCSE Biology 1.1 Cell structures, covering 1.1.1 Viewing cells with light microscopes, 1.1.2 Sub-cellular structures and functions, and 1.1.3 Electron microscopy and resolution. Each one has a worked solution and a mark scheme showing where the marks go.
