Question 15

A researcher measures four microscope images of algae cells and records a magnification claim for each sample.

Sample	Length of image in $mm\text{mm}$	Actual length in $mm\text{mm}$	Recorded magnification claim
K	24	0.08	$×300\times300$
L	36	0.06	$×60\times60$
M	18	0.09	$×1.62\times1.62$
N	32	0.04	$×0.00125\times0.00125$

Which sample has a recorded magnification claim supported by its measurements?

[1]

Sample L

Sample N

Sample K

Sample M

Markscheme

1.1 Cell structures Questions

GCSE
Biology
1.1 Cell structures

130 exam-style questions on OCR GCSE Biology 1.1 Cell structures, covering 1.1.1 Viewing cells with light microscopes, 1.1.2 Sub-cellular structures and functions, and 1.1.3 Electron microscopy and resolution. Each one has a worked solution and a mark scheme showing where the marks go.
