A laboratory technician passes a direct current through acidified water using inert electrodes. The gases produced at the two electrodes are collected separately.
The mass of water decomposed is 0.090 g.
One mole of any gas occupies 24 000 cm3\mathrm{cm^{3}}cm3 at room temperature and pressure.
Relative formula mass: H2O\mathrm{H_{2}O}H2O = 18
Which row shows the volumes of gas produced at the cathode and at the anode?
120 cm3\mathrm{cm^{3}}cm3 at the cathode and 60 cm3\mathrm{cm^{3}}cm3 at the anode
240 cm3\mathrm{cm^{3}}cm3 at the cathode and 120 cm3\mathrm{cm^{3}}cm3 at the anode
60 cm3\mathrm{cm^{3}}cm3 at the cathode and 120 cm3\mathrm{cm^{3}}cm3 at the anode
120 cm3\mathrm{cm^{3}}cm3 at the cathode and 120 cm3\mathrm{cm^{3}}cm3 at the anode
110 exam-style questions on Edexcel GCSE Chemistry 4.2 Electrolytic processes, covering 4.2.1 Electrolytes and the process of electrolysis, 4.2.2 Products of electrolysis using inert electrodes, 4.2.3 Half equations, oxidation and reduction in electrolysis, and 4.2.4 Electrolysis of copper sulfate and purifying copper. Each one has a worked solution and a mark scheme showing where the marks go.
