A researcher prepared a transverse section of mammalian skeletal muscle tissue to view under an optical microscope. The researcher cut an extremely thin slice of the muscle tissue.
Explain why it is essential to prepare a very thin slice of the tissue specimen for viewing under an optical microscope.
The researcher used an optical microscope with a magnification of ×400\times 400×400 to view the muscle fibers. They used a ruler with 1 mm graduations to measure the diameter of five skeletal muscle fibers on the printed micrograph. The measured diameters on the image were: 18 mm, 22 mm, 19 mm, 21 mm, and 20 mm.
Calculate the mean actual diameter, in μm\mu\text{m}μm, of these muscle fibers. Show your working.
Give the absolute uncertainty associated with taking a measurement of a fiber diameter using a ruler with 1 mm graduations, assuming the uncertainty is equal to the resolution of 1 mm (due to two readings being taken). Calculate the percentage error for a fiber diameter measurement of 16 mm using this ruler.
25 exam-style questions on AQA A Level Biology Cell structure, covering Structure of eukaryotic cells, Structure of prokaryotic cells and of viruses, and Methods of studying cells. Each one has a worked solution and a mark scheme showing where the marks go.
