A food-drying system removes water vapour from moist air. In the condenser, the water vapour changes into liquid water without a change in temperature.
During one drying cycle, cooling water flows through the condenser and is heated by the condensing water vapour. Assume that all the energy transferred from the condensing water vapour increases the thermal energy of the cooling water.
| Quantity | Value |
|---|---|
| Mass of cooling water that flows through the condenser in one cycle | 3.0 kg |
| Initial temperature of cooling water | 15.0 ∘C15.0\ ^\circ\text{C}15.0 ∘C |
| Final temperature of cooling water | 19.0 ∘C19.0\ ^\circ\text{C}19.0 ∘C |
| Specific heat capacity of water | 4200 J/kg ∘C4200\ \text{J/kg}\, ^\circ\text{C}4200 J/kg∘C |
| Specific latent heat of vaporisation of water | 2.40 × 106 J/kg |
Explain, in terms of particles, why energy is transferred from the water vapour as it condenses even though its temperature does not change.
Calculate the mass of water vapour that condenses during one drying cycle.
114 exam-style questions on AQA GCSE Physics 3.2 Internal energy and energy transfers, covering 3.2.1 Internal energy, 3.2.2 Temperature changes in a system and specific heat capacity, and 3.2.3 Changes of state and specific latent heat. Each one has a worked solution and a mark scheme showing where the marks go.
