Question 2

A test circuit has a 12 V supply, an 8.0 Ω resistor and a second resistor, all connected in series. The circuit works correctly only if the potential difference across the 8.0 Ω resistor is at least 3.5 V. The second resistor is chosen so that, with the 12 V supply, the potential difference across the 8.0 Ω resistor is 4.0 V.

a.

Calculate the resistance of the second resistor.

[3]
b.

The 12 V supply is replaced by a 9.0 V battery. The second resistor is not changed.

Determine whether the circuit still works correctly.

[3]
