Question 14
HA student investigates the efficiency of a small electric motor.
The Figure shows the apparatus.
Figure
The motor lifts a mass of 0.20 kg through a height of 0.80 m. The reading on the joulemeter increases by 4.0 J.
Gravitational field strength = 10 N/kg
a.[3]
Calculate the efficiency of the motor.
b.
[2]
The student repeats the experiment with different masses.
The Table shows her results.
Table
| Mass lifted in kg\text{kg}kg | Efficiency |
|---|---|
| 0.10 | 0.25 |
| 0.20 | 0.40 |
| 0.30 | 0.48 |
| 0.40 | 0.44 |
| 0.50 | 0.35 |
Describe how the efficiency of the motor depends on the mass lifted.
c.[2]
Describe how the student could measure the height that the mass is lifted through as accurately as possible.
d.[1]
Suggest one way of increasing the efficiency of the motor.
