15.2 Pressure in fluids

EasyMediumHard
12345678910111213141516171819202122232425262728293031323334353637383940414243444546474849505152535455
Question 14

A modular walkway rests on five identical pads on level ground. The total weight of the walkway and anything on it is shared equally between the pads. Each pad has a contact area of 0.025 m2. The ground can withstand a pressure of up to 80 000 Pa80\,000\ \mathrm{Pa}80000 Pa.

What is the greatest total weight that the walkway and its load can have?

[1]
A

640 000 N640\,000\ \mathrm{N}640000 N

B

2 000 N2\,000\ \mathrm{N}2000 N

C

400 N400\ \mathrm{N}400 N

D

10 000 N10\,000\ \mathrm{N}10000 N

Markscheme

15.2 Pressure in fluids Questions

  1. GCSE
  2. /Physics
  3. /15.2 Pressure in fluids

132 exam-style questions on Edexcel GCSE Physics 15.2 Pressure in fluids, covering 15.2.1 Atmospheric pressure and height, 15.2.2 Pressure in fluids, 15.2.3 Pressure, force and area, 15.2.4 Pressure and depth, 15.2.5 Pressure in liquids: depth and density, 15.2.6 Upthrust, and 15.2.7 Floating and sinking. Each one has a worked solution and a mark scheme showing where the marks go.
