Figure 1 shows the magnetic field pattern produced in and around the gap of a C-shaped magnet.

Figure 1: Diagram showing the magnetic field lines in and around the gap between the N and S poles of a magnet.

Describe two differences between the magnetic field in the region directly between the poles and the magnetic field in the region outer to the poles (above or below the gap).

[2]
