An electronics technician investigated how the current in a test circuit varied with the resistance of a calibration rheostat (a variable resistor).
The table below shows the results of their investigation:
| Resistance of rheostat, RRR (Ω\OmegaΩ) | Current in circuit, III (A) |
|---|---|
| 20 | 0.60 |
| 30 | 0.40 |
| 40 | 0.30 |
| 60 | 0.20 |
| 80 | 0.15 |
The DC power supply had a power output of 1.80 W1.80\text{ W}1.80 W when the resistance of the rheostat was 80 Ω80\ \Omega80 Ω.
Determine the terminal potential difference across the power supply.
The technician concluded:
'The current in the circuit was inversely proportional to the resistance of the rheostat.'
Explain how the table of results shows that this conclusion is correct.
The technician then connected a bypass switch incorrectly, as shown in the circuit diagram below:
Explain how closing the switch would affect the current in the rheostat.
