Vectors

A vector diagram showing points O, J, K, and M. Vector OJ is labeled 7p and vector OK is labeled 5q. M is the midpoint of the line segment JK.

The diagram shows a triangle $O J K$ .

\overrightarrow{OJ} = 7\mathbf{p}

\overrightarrow{OK} = 5\mathbf{q}

M is the midpoint of $J K$

Find, in terms of $p\mathbf{p}$ and $q\mathbf{q}$ , the vector $JK→\overrightarrow{JK}$ .

[1]

Find, in terms of $p\mathbf{p}$ and $q\mathbf{q}$ , the vector $JM→\overrightarrow{JM}$ .

[1]

Find, in terms of $p\mathbf{p}$ and $q\mathbf{q}$ , the vector $OM→\overrightarrow{OM}$ .

[2]

Vectors Questions

74 exam-style questions on Edexcel GCSE Maths Vectors. Each one has a worked solution and a mark scheme showing where the marks go.

Question bank·Vectors
