A wooden display block is carved into a prism with an L-shaped cross-section. The dimensions are shown in the diagram.

Find the total surface area of the block.

An L-shaped prism. The face has a base of 12 cm and a height of 8 cm. The wider vertical section is 8 cm wide and 8 cm high. The narrower section attached to the right is 4 cm wide and 3 cm high. The prism has a depth of 15 cm.

[4]
