Draw a logic circuit for the following Boolean expression:

Y=NOT(P OR Q) AND R Y = \text{NOT}(P \text{ OR } Q) \text{ AND } R Y=NOT(P OR Q) AND R

Logic circuit template with inputs P, Q, R on the left and output Y on the right

[3]

Boolean logic Questions

Practise OCR GCSE Computer Science Boolean logic with exam-style questions for GCSE Computer Science. 27 questions, matched to the OCR GCSE Computer Science (J277) specification and written in Component 01 and Component 02 style. Every question includes a full worked solution and mark scheme, so you can see where marks are awarded rather than just whether you got the answer right.
