A process engineer uses a pilot fractionating column to separate a vapour mixture containing alkanes R and S. The vapour enters below tray 1 and rises through trays 1, 2 and 3, in that order.

The table shows the current temperature of each tray.

Tray	Temperature ( $∘C^\circ\mathrm{C}$ )
3	95
2	140
1	180

Alkane	Boiling point ( $∘C^\circ\mathrm{C}$ )
R	126
S	151

The engineer proposes lowering the temperature of tray 2 to $∘C120\,^\circ\mathrm{C}$ , while leaving the other tray temperatures unchanged. The engineer claims that this change will improve the separation of R and S.

Evaluate the engineer's claim.

A process engineer uses a pilot fractionating column to separate a vapour mixture containing alkanes R and S. The vapour enters below tray 1 and rises through trays 1, 2 and 3, in that order.

The table shows the current temperature of each tray.

Tray	Temperature ( $∘C^\circ\mathrm{C}$ )
3	95
2	140
1	180

Alkane	Boiling point ( $∘C^\circ\mathrm{C}$ )
R	126
S	151

Evaluate the engineer's claim.
