1.1.1a Atoms, elements and compounds

Atoms and elements: every substance is built from atoms

Definition

Element

A substance made of atoms that all have the same number of protons.

  1. All substances are made of atoms, whether they are solids, liquids or gases.
  2. An atom is the smallest part of an element that can exist.
  3. An element is a substance made from only one type of atom.
  4. About 100 different elements are known, and they are set out in the periodic table.
  5. Each element in the periodic table is shown by its name and its chemical symbol.
Key Idea
  • Every atom belongs to an element, such as oxygen, carbon or sodium.
  • A substance containing only one type of atom is an element.

Chemical symbols: each element has its own abbreviation

Definition

Chemical symbol

A one-letter or two-letter abbreviation used to represent an atom of a particular element.

  1. Each element is represented by a chemical symbol made of one or two letters.
  2. The first letter is always a capital; the second letter, when present, is always lower-case.
  3. The symbol O\text{O}O means one oxygen atom, while Na\text{Na}Na means one sodium atom.
  4. You are given a periodic table in the exam, so you can match element names to symbols.
  5. The first 20 elements are H, He, Li, Be, B, C, N, O, F, Ne\text{H, He, Li, Be, B, C, N, O, F, Ne}H, He, Li, Be, B, C, N, O, F, Ne then Na, Mg, Al, Si, P, S, Cl, Ar, K, Ca\text{Na, Mg, Al, Si, P, S, Cl, Ar, K, Ca}Na, Mg, Al, Si, P, S, Cl, Ar, K, Ca.
  6. Other elements to recognise include the Group 1 metals Rb, Cs\text{Rb, Cs}Rb, Cs, the Group 7 elements Br, I\text{Br, I}Br, I, and transition metals such as Fe, Cu, Zn, Ag, Au\text{Fe, Cu, Zn, Ag, Au}Fe, Cu, Zn, Ag, Au.
Common Mistake
  • Do not change the capitalisation: Co\text{Co}Co is cobalt but CO\text{CO}CO is carbon monoxide.
  • Some symbols come from Latin names, so you cannot guess them, such as sodium Na\text{Na}Na and iron Fe\text{Fe}Fe.

Compounds: elements join in fixed proportions

Definition

Chemical formula

A combination of element symbols and numbers that shows which elements are present in a substance and their relative numbers of atoms.

  1. A compound contains two or more different elements chemically combined in fixed proportions.
  2. Fixed proportions means every sample of the compound has its elements in the same ratio.
  3. A chemical formula uses symbols and numbers to show which atoms are present and in what ratio.
  4. A subscript is the small lower number showing how many atoms of the element before it are present.
  5. No subscript after a symbol means one atom of that element in the simplest particle.
  6. H2O\text{H}_2\text{O}H2​O shows water has hydrogen and oxygen in a fixed ratio of 2:12:12:1.
  7. CO2\text{CO}_2CO2​ shows carbon dioxide has carbon and oxygen in a fixed ratio of 1:21:21:2.
  8. Different proportions give different compounds, such as carbon monoxide CO\text{CO}CO and carbon dioxide CO2\text{CO}_2CO2​.
Example
  • One particle of H2O\text{H}_2\text{O}H2​O has two hydrogen atoms and one oxygen atom.
  • Ten particles of H2O\text{H}_2\text{O}H2​O have 20 hydrogen and 10 oxygen atoms, so the ratio stays 2:12:12:1.

Chemical reactions: new substances form when atoms rearrange

Definition

Chemical reaction

A change in which one or more new substances are formed, often accompanied by an energy change.

  1. A chemical reaction forms one or more new substances.
  2. The starting substances are the reactants, and the substances formed are the products.
  3. Elements join to form compounds through chemical reactions.
  4. The products have different properties from the reactants because they are new substances.
  5. Reactions often involve a detectable energy change, seen as a temperature change or the giving out of light.
  6. A compound can be split into its elements only by chemical reactions, because its chemical bonds must be broken.
  7. A physical method alone cannot separate a compound into its elements.
Note
  • A temperature change or light can be evidence that a reaction has happened.
  • No obvious energy change does not prove that no reaction took place.

Names and formulae: read each symbol before naming the compound

Definition

Subscript

A small lower number in a chemical formula that shows how many atoms of the element immediately before it are present.

  1. Two-element compounds: the first element keeps its name and the second ends in -ide.
    1. NaCl\text{NaCl}NaCl is sodium chloride, MgO\text{MgO}MgO is magnesium oxide and CaCl2\text{CaCl}_2CaCl2​ is calcium chloride.
  2. Named groups: CaCO3\text{CaCO}_3CaCO3​ is calcium carbonate, CuSO4\text{CuSO}_4CuSO4​ is copper sulfate, KNO3\text{KNO}_3KNO3​ is potassium nitrate and NaOH\text{NaOH}NaOH is sodium hydroxide.
  3. Common acids: HCl\text{HCl}HCl is hydrochloric acid, H2SO4\text{H}_2\text{SO}_4H2​SO4​ is sulfuric acid and HNO3\text{HNO}_3HNO3​ is nitric acid.
  4. Diatomic elements exist as two-atom molecules: H2,N2,O2,F2,Cl2,Br2,I2\text{H}_2, \text{N}_2, \text{O}_2, \text{F}_2, \text{Cl}_2, \text{Br}_2, \text{I}_2H2​,N2​,O2​,F2​,Cl2​,Br2​,I2​.
  5. Other key formulae are water H2O\text{H}_2\text{O}H2​O, carbon dioxide CO2\text{CO}_2CO2​, methane CH4\text{CH}_4CH4​ and ammonia NH3\text{NH}_3NH3​.
Common Mistake
  • Do not write chlorine as Cl\text{Cl}Cl when it is an element: elemental chlorine is Cl2\text{Cl}_2Cl2​.
  • Never change a subscript to balance an equation, because that changes the substance.

Chemical equations: balancing keeps every atom accounted for

Definition

Coefficient

A large whole number placed before a chemical formula to show the relative number of particles or moles in a balanced equation.

  1. A word equation shows a reaction using the names of reactants and products.
  2. The reactants go on the left of the arrow and the products on the right, separated by plus signs.
  3. The word equation for magnesium burning in oxygen is:
    1. magnesium+oxygen→magnesium oxide\text{magnesium} + \text{oxygen} \rightarrow \text{magnesium oxide}magnesium+oxygen→magnesium oxide
  4. A symbol equation shows the same reaction using formulae, which must be correct before balancing:
    1. Mg(s)+O2(g)→MgO(s)\text{Mg(s)} + \text{O}_2\text{(g)} \rightarrow \text{MgO(s)}Mg(s)+O2​(g)→MgO(s)
  5. A balanced equation has the same number of atoms of each element on both sides.
  6. A coefficient is a large whole number before a formula that multiplies every atom in it.
  7. Balance in steps: count the atoms on each side, add coefficients until they match, then check using the smallest whole numbers.
  8. The balanced equation for magnesium and oxygen is:
    1. 2Mg(s)+O2(g)→2MgO(s)2\text{Mg(s)} + \text{O}_2\text{(g)} \rightarrow 2\text{MgO(s)}2Mg(s)+O2​(g)→2MgO(s)
  9. This now has two magnesium atoms and two oxygen atoms on each side.
  10. The state symbols (s),(l),(g),(aq)\text{(s)}, \text{(l)}, \text{(g)}, \text{(aq)}(s),(l),(g),(aq) mean solid, liquid, gas and dissolved in water.
  11. Always balance by changing coefficients only, never by changing formulae.
Self review
  • What is an atom?
  • What does CO2\text{CO}_2CO2​ tell you about carbon dioxide?
  • Why can a compound be separated only by chemical reactions?
  • What is the formula of elemental chlorine?
  • Balance H2+O2→H2O\text{H}_2 + \text{O}_2 \rightarrow \text{H}_2\text{O}H2​+O2​→H2​O.
Next

How was this guide?

Teach Genie

Review 1.1.1a Atoms, elements and compounds by teaching Genie

Teach it back in your own words, spot gaps, and remember it better.

Start teaching
Genie and Baby Genie

Lesson

Recap your knowledge with an interactive lesson

8 minute activity

Start lesson

In particle diagrams, particles sharing a colour represent atoms of the same element. Particles shown in different colours, such as dark-blue and light-blue particles, represent atoms of different elements.

All substances are made from atoms. An element is a substance made from only one type of atom, while a compound contains atoms of two or more different elements chemically joined in fixed proportions.

An atom is the smallest part of an element that can exist. Each element is represented by a chemical symbol, such as O\text{O}O for one oxygen atom and Na\text{Na}Na for one sodium atom.

A compound's formula shows which elements are present and their relative numbers of atoms. In H2O\text{H}_2\text{O}H2​O, the subscript 2 means two hydrogen atoms, while the lack of a subscript means one oxygen atom.
