Capacitors

EasyMediumHard
1
Question 1

A student plots a graph of charge Q Q\,Q on the vertical axis against potential difference V V\,V on the horizontal axis for a capacitor as it is being charged.

Which of the following pairs of quantities can be determined from the gradient of the graph and the area under the graph, respectively?

A

capacitance, energy stored

B

capacitance, power

C

resistance, energy stored

D

resistance, charge

Markscheme

Capacitors Questions

  1. A Level
  2. /Physics
  3. /Capacitors

22 exam-style questions on OCR A A Level Physics Capacitors, covering Capacitors, Energy, and Charging and discharging capacitors. Each one has a worked solution and a mark scheme showing where the marks go.
