7.1 Work done

EasyMediumHard
123456789101112131415161718192021222324252627282930
Question 5
F

A student heats a 1.0 kg aluminium block using an electric heater. A joulemeter measures the energy transferred to the heater.

Her results are:

  • energy transferred to the heater =19 200 J= 19\ 200\ \text{J}=19 200 J
  • temperature of the block at the start =21 ∘C= 21\ ^\circ\text{C}=21 ∘C
  • temperature of the block at the end =41 ∘C= 41\ ^\circ\text{C}=41 ∘C
a.

Calculate the change in temperature of the block.

[1]
b.

Use the equation: change in thermal energy=mass×specific heat capacity×change in temperature\text{change in thermal energy} = \text{mass} \times \text{specific heat capacity} \times \text{change in temperature}change in thermal energy=mass×specific heat capacity×change in temperature

Calculate the specific heat capacity of aluminium from the student's results.

Give the unit.

[3]
c.

The accepted value for the specific heat capacity of aluminium is 900 J/kg ∘C900\ \text{J/kg}\ ^\circ\text{C}900 J/kg ∘C.

Explain why the student's value is higher than the accepted value.

[2]
d.

Suggest one change to the method that would make the student's value closer to the accepted value.

[1]
Markscheme

7.1 Work done Questions

  1. GCSE
  2. /Physics
  3. /7.1 Work done

44 exam-style questions on OCR GCSE Physics 7.1 Work done, covering 7.1.1 Conservation of energy in a closed system, 7.1.2 Energy stores and transfers, 7.1.3 Energy changes by heating, forces and current, 7.1.4 Quantifying energy transfers in a system, and 7.1.5 Kinetic, elastic and gravitational potential energy. Each one has a worked solution and a mark scheme showing where the marks go.
