The Table shows the orbital radius and orbital speed of four satellites, A, B, C and D. Each satellite is in a stable circular orbit around the Earth.
Table
| Satellite | Orbital radius in km\text{km}km | Orbital speed in km/s\text{km/s}km/s |
|---|---|---|
| A | 6700 | 7.7 |
| B | 7000 | 7.5 |
| C | 26 60026\ 60026 600 | 3.9 |
| D | 42 20042\ 20042 200 | 3.1 |
Describe how the orbital speed of a satellite depends on its orbital radius.
Satellite D is in a geostationary orbit.
The circumference of a circle =2π×radius= 2\pi \times \text{radius}=2π×radius
Show that satellite D takes about 24 hours to complete one orbit.
Explain why satellite A must move faster than satellite D to stay in a stable orbit.
