15.2 Pressure in fluids

EasyMediumHard
123456789101112131415161718192021222324252627
Question 27

A pneumatic actuator is used to raise a workshop shutter.

Compressed air produces a pressure difference of 160 000 Pa160\,000\ \text{Pa}160000 Pa across the actuator's piston. The piston has an area of 0.0015 m2.

To lift the shutter, the actuator must push upwards on it with a force of more than 220 N.

Explain whether the actuator raises the shutter.

Your answer should include a calculation.

[3]
Markscheme

15.2 Pressure in fluids Questions

  1. GCSE
  2. /Physics
  3. /15.2 Pressure in fluids

132 exam-style questions on Edexcel GCSE Physics 15.2 Pressure in fluids, covering 15.2.1 Atmospheric pressure and height, 15.2.2 Pressure in fluids, 15.2.3 Pressure, force and area, 15.2.4 Pressure and depth, 15.2.5 Pressure in liquids: depth and density, 15.2.6 Upthrust, and 15.2.7 Floating and sinking. Each one has a worked solution and a mark scheme showing where the marks go.
