15.2 Pressure in fluids

EasyMediumHard
12345678910111213141516171819202122232425262728293031323334353637383940414243444546474849505152535455
Question 11

A rectangular flexible membrane in a water-treatment unit separates liquid at two different pressures. The pressure on one side of the membrane is 1200 Pa greater than the pressure on the other side. The membrane measures 30 cm by 25 cm.

What resultant force acts on the membrane because of the difference in liquid pressure?

[1]
A

660 N660\ \mathrm{N}660 N

B

9000 N9000\ \mathrm{N}9000 N

C

90 N90\ \mathrm{N}90 N

D

300 N300\ \mathrm{N}300 N

Markscheme

15.2 Pressure in fluids Questions

  1. GCSE
  2. /Physics
  3. /15.2 Pressure in fluids

132 exam-style questions on Edexcel GCSE Physics 15.2 Pressure in fluids, covering 15.2.1 Atmospheric pressure and height, 15.2.2 Pressure in fluids, 15.2.3 Pressure, force and area, 15.2.4 Pressure and depth, 15.2.5 Pressure in liquids: depth and density, 15.2.6 Upthrust, and 15.2.7 Floating and sinking. Each one has a worked solution and a mark scheme showing where the marks go.
