An inspection camera is lowered into a tank containing hydraulic oil.
The camera is positioned below the surface of the oil.
| quantity | value |
|---|---|
| vertical depth of the camera | 2.0 m |
| density of the hydraulic oil | 850 kg/m3 |
| gravitational field strength | 10 N/kg |
Calculate the rise in pressure between the oil surface and the camera.
Use the equation
P=h×ρ×gP = h \times \rho \times gP=h×ρ×g
132 exam-style questions on Edexcel GCSE Physics 15.2 Pressure in fluids, covering 15.2.1 Atmospheric pressure and height, 15.2.2 Pressure in fluids, 15.2.3 Pressure, force and area, 15.2.4 Pressure and depth, 15.2.5 Pressure in liquids: depth and density, 15.2.6 Upthrust, and 15.2.7 Floating and sinking. Each one has a worked solution and a mark scheme showing where the marks go.
