9.2 Moments

EasyMediumHard
1234567891011121314151617181920212223242526272829303132333435363738394041424344
Question 30

The lid of an industrial mixing vessel is held horizontally and can turn about a hinge. The weight of the lid produces a clockwise moment of 24 N m about the hinge. A filter unit of weight 180 N acts at a perpendicular distance of 0.20 m from the hinge and also produces a clockwise moment. A hydraulic actuator exerts a force at a perpendicular distance of 0.40 m from the hinge, producing an anticlockwise moment about the hinge. What force must the actuator exert to keep the lid in rotational equilibrium?

[1]
A

90 N90\ \mathrm{N}90 N

B

240 N240\ \mathrm{N}240 N

C

150 N150\ \mathrm{N}150 N

D

60 N60\ \mathrm{N}60 N

Markscheme

9.2 Moments Questions

  1. GCSE
  2. /Physics
  3. /9.2 Moments

102 exam-style questions on Edexcel GCSE Physics 9.2 Moments, covering 9.2.1 Rotational effects of forces and moments, 9.2.2 The principle of moments, and 9.2.3 Levers and gears. Each one has a worked solution and a mark scheme showing where the marks go.
