A sealed air spring in a suspension test rig contains a fixed mass of air. An additional load compresses the air spring.
The temperature of the air remains constant.
| condition | pressure in kPa | volume in litres |
|---|---|---|
| before the additional load is applied | 250 | 18 |
| after the additional load is applied | 450 | to be calculated |
Calculate the volume of the air spring after the additional load is applied.
Use the equation
p1×V1=p2×V2p_1 \times V_1 = p_2 \times V_2p1×V1=p2×V2
108 exam-style questions on Edexcel GCSE Physics 14.3 Gas pressure and temperature, covering 14.3.1 Gas pressure and particle motion, 14.3.2 Temperature and pressure at constant volume, 14.3.3 Absolute zero and the kelvin scale, 14.3.4 Compressing and expanding gases, 14.3.5 Volume and pressure at constant temperature, and 14.3.6 Doing work on a gas. Each one has a worked solution and a mark scheme showing where the marks go.
