9.1 Forces and vectors

EasyMediumHard
123456789101112131415161718192021222324252627282930313233343536373839404142
Question 5

A powered launch tows an unmanned survey float in a straight line across still water. The tow rope remains taut.

The motor provides a horizontal thrust of 500 N. The resistive forces act in the opposite direction to the motion.

At one instant, the launch and the survey float accelerate together at 1.0 m/s2.

ObjectMassResistive force
Powered launch180 kg80 N
Survey float60 kgunknown
a.

Calculate the resistive force acting on the survey float.

[4]
b.

Calculate the tension in the tow rope.

[2]
c.

The resistive force on the survey float later becomes 240 N. The thrust and the resistive force on the powered launch do not change.

Explain whether the tension in the tow rope increases, decreases or stays the same.

[3]
Markscheme

9.1 Forces and vectors Questions

  1. GCSE
  2. /Physics
  3. /9.1 Forces and vectors

93 exam-style questions on Edexcel GCSE Physics 9.1 Forces and vectors, covering 9.1.1 Interactions and types of force, 9.1.2 Vector and scalar quantities, and 9.1.3 Vector diagrams and free body diagrams. Each one has a worked solution and a mark scheme showing where the marks go.
