A museum display is powered by a battery. Switch M and lamp L are in the main wire before the wire divides into two branches. One branch contains switch S and lamp P in series. The other branch contains lamps Q and R in series. The branches then rejoin and return to the battery.
All four lamps are working correctly. Between Test 1 and Test 2, the position of exactly one switch is changed.
| Test | Lamp L | Lamp P | Lamp Q | Lamp R |
|---|---|---|---|---|
| 1 | lit | not lit | lit | lit |
| 2 | not lit | not lit | not lit | not lit |
Explain the positions of switches S and M during Test 1 and Test 2.
