Circle Theorems
66
Medium
0/4

A geometric diagram showing a circle with center O. A horizontal line DCE is tangent to the circle at point C. Points A and B are on the circumference. Chords AC and BC are drawn. A radius OC is drawn from the center O to the point of tangency C. The angle between the radius OC and the tangent line CE is labeled 65°. Chords AB and BC are marked with single tick marks, indicating they are of equal length.

AAA, B B\,B and C C\,C are points on the circumference of a circle, centre OOO. DCE DCE\,DCE is a tangent to the circle.

AB=BCAB = BCAB=BC Angle BCE=65∘BCE = 65^\circBCE=65∘

Find the size of angle AOCAOCAOC.

You must show all your working.

[4]

Circle Theorems Questions

Practise Edexcel GCSE Maths Circle Theorems with exam-style questions for Foundation and Higher tier. 72 questions, matched to the Edexcel GCSE Maths (1MA1) specification and written in Paper 1, Paper 2 and Paper 3 style. Every question includes a full worked solution and mark scheme, so you can see where marks are awarded rather than just whether you got the answer right.
