Angles in Parallel Lines
7
Hard
0/3

Diagram

PQRS PQRS\,PQRS is a parallelogram. T T\,T is a point on the diagonal QSQSQS.

Angle SPT=48∘SPT = 48^\circSPT=48∘ Angle QRS=118∘QRS = 118^\circQRS=118∘ Angle RQS=32∘RQS = 32^\circRQS=32∘

Calculate the size of angle xxx (angle PTQPTQPTQ).

Give reasons for each stage of your answer.

[3]

Angles in Parallel Lines Questions

Practise Edexcel GCSE Maths Angles in Parallel Lines with exam-style questions for Foundation and Higher tier. 32 questions, matched to the Edexcel GCSE Maths (1MA1) specification and written in Paper 1, Paper 2 and Paper 3 style. Every question includes a full worked solution and mark scheme, so you can see where marks are awarded rather than just whether you got the answer right.
