Question 6
Medium

The table shows data about three different substances:

SubstanceMelting point (°C\degree\text{C}°C)Boiling point (°C\degree\text{C}°C)Conducts electricity as a solid?Conducts electricity when molten?
X10852562YesYes
Y-114-85NoNo
Z8011413NoYes
a.

Identify which substance (X, Y, or Z) is a simple covalent substance and explain your choice using evidence from the table.

[2]
b.

State the physical state of substance Y at room temperature (20degC).

[1]
c.

The diagram below represents the arrangement of atoms in a brass alloy:

A close-packed arrangement of 24 circles. There are exactly 15 large, dark-grey circles representing copper atoms and 9 smaller, white circles representing zinc atoms, mixed together in a disordered layer structure.

Determine the simplest whole-number ratio of copper to zinc atoms shown in this alloy diagram.

[2]
d.

Explain why brass is harder than pure copper.

[2]
