Elements R and Q react to form a solid compound.
| Element | Type of element | Electronic structure of atom |
|---|---|---|
| R | metal | 2,8,1 |
| Q | non-metal | 2,6 |
Three students each built a model of a small section of the solid compound. The table shows the number of particles of R and of Q in each model.
| Model | Number of R particles | Number of Q particles |
|---|---|---|
| A | 8 | 4 |
| B | 6 | 6 |
| C | 4 | 8 |
Use the information in both tables. Describe the electron changes that happen when atoms of R react with atoms of Q. Use these changes to identify which model, A, B or C, has the correct ratio of particles and to give the empirical formula of the compound. Then describe the structure and bonding in the solid compound.
